4/7.5 cleaning truck suction sewage truck
左前
正前
右前
右侧
右后
正后
左后
左侧
左前
正前
右前
右侧
右后
正后
左后
左侧
+86 0722-3800399
Product Description

The 4/7.5m cleaning and suction truck is a multifunctional sanitation special vehicle integrating high-pressure cleaning and vacuum suction. The volume of the clear water tank is 4 cubic meters and the volume of the sewage tank is 7.5 cubic meters. This model is especially suitable for dredging and cleaning of urban roads, sewers, culverts and septic tanks. The 4/7.5m cleaning and suction truck is equipped with a high-efficiency vacuum suction pump and a strong high-pressure water pump, which is easy to operate and efficient. With excellent adaptability and flexibility, the 4/7.5m cleaning and suction truck has become one of the preferred equipment for many municipal sanitation units.

Product details and features

Function Description: The 4/7.5m cleaning and suction truck has the dual functions of high-pressure washing and sewage extraction, and is widely used in cleaning and dredging operations of urban sewage pipelines, rainwater wells and sewers.

Product Highlights: The 4/7.5m cleaning and suction truck is equipped with a large flow vacuum pump and a high pressure cleaning pump, which have significant advantages such as high suction efficiency, large cleaning pressure and excellent sealing performance.

Applicable Scenarios: Whether it is the main road in the city, the alley in the village in the city, or the industrial factory and campus, the 4/7.5m cleaning and suction truck can enter and leave flexibly and adapt to various complex working conditions.

Design Advantages: The 4/7.5m cleaning and suction truck adopts a sub-warehouse structure, clean water and sewage are separated and arranged, the tank material is corrosion-resistant, the vehicle has high stability, and is convenient for operation and maintenance.

supports customization: non-standard customization of pump model, tank material, nozzle layout, pipeline configuration, etc. of 4/7.5m cleaning and suction truck can be carried out according to user requirements.

Quality Assurance: All 4/7.5m ³ cleaning and suction trucks are manufactured using international standard processes. Through strict quality inspection procedures, the safety and reliability of the entire vehicle in long-term use are guaranteed.

Contact Us
We will reply within 5 minutes of working time
Quote Now
Technical parameters
Standard Optional None
Basic information
  • Vehicle modelCLW5120GQWE6
  • Chassis modelEQ1125SJ8CDC
  • Energy TypeDiesel
  • Maximum speed100
  • Engine power (KW)96
    103
    110
    121
Body
  • Overall dimension L×W×H(mm)7050×2250×2880
  • Vehicle length (mm)7050
  • Vehicle width (mm)2250
  • Vehicle height (mm)2880
  • Wheelbase (mm)3800
  • Front track (mm)1745
  • Rear track (mm)1630
  • Minimum ground clearance (mm)420
  • Curb weight (kg)7340
  • Full load mass (kg)11995
  • Rated load mass (kg)4460
  • Fuel tank volume (L)150
  • Number of doors (unit)2
  • Number of seats (pieces)2 to 3
Engine
  • Displacement (ml)2360
  • Engine boost
Motor
  • Number of drive motors (pts)None
Generator
  • Whether to configure🔧 Optional
  • Rated power (KW)2
  • Voltage/Current Display🔧 Optional
  • Type of fuelDiesel
  • Startup TypeElectric start
  • Noise level (db) ≤ 80db
  • Frequency and voltage stabilization
Gearbox
  • Number of gears (unit)6
  • Gearbox typeManual
Chassis/Steering
  • Driving mode4 x 2
  • Steering assist typeHydraulic boost
Active safety
  • ABS anti-lock🔧 Optional
Passive Safety
  • Tire pressure monitoring system🔧 Optional
  • Explosion-proof tire🔧 Optional
Auxiliary/Control Configuration
  • Driving assistance image🔧 Optional
  • Level of driving assistanceNone
  • Air suspension🔧 Optional
Comfort/anti-theft configuration
  • Central lock in the car 🔧 Optional
  • Remote Key Type 🔧 Optional
  • Built-in driving recorder 🔧 Optional
  • Satellite navigation system 🔧 Optional
  • 110V/220V/230V power socket 🔧 Optional
Seat configuration
  • Seat materialCloth seats
  • Electric seat adjustment
  • Driver's seat adjustment
  • Passenger Seat Adjustment
  • Front seat functionNone
  • Second row seat functionNone
Intelligent interconnection
  • Car Radio
  • Mobile phone interconnection mapping
  • Car networking
  • 4G/5G network
  • AV system
  • Multimedia Interface
Lighting
  • Low beam ✓ Standard
  • High beam ✓ Standard
  • Lifting lamp 🔧 Optional
  • Lifting height of lifting lamp (mm) 1200
  • Number of Lifting Lights (unit) 2
  • Total power of lifting lamp (KW) 127
  • Parking warning light ✓ Standard
  • Parking lights on both sides 🔧 Optional
  • Rear parking lamp 🔧 Optional
  • Steering assist lamp ✓ Standard
  • Front/rear fog lights ✓ Standard
Glass/Mirror
  • Power windows 🔧 Optional
  • One-button window lift 🔧 Optional
  • Exterior rearview mirror function ✓ Standard
  • Interior rearview mirror function ✓ Standard
  • Interior makeup mirror ✓ Standard
  • Interior sunshade 🔧 Optional
  • Front Windshield Defrosting ✓ Standard
Air conditioning
  • Air conditioning configuration ✓ Standard
  • Air conditioning type Air conditioning
  • Effective regulation area (㎡)≥ 18.00
  • Air conditioning core function Temperature regulation
Intelligent configuration
  • Exterior camera head 🔧 Optional
  • High-precision maps 🔧 Optional
Fire protection system
  • Dry powder fire extinguisher ✓ Standard
Tank/Container
  • Material Carbon steel
  • Water tank volume (m³) 4.00
  • Gas tank volume (m³) 7.50
Other working parameters
  • Suction speed (m³/min) 9.00
  • Flow (L/S) 10.00
  • Maximum allowable diameter of material passing through (mm) 60.00
  • Operating speed (m/min) 20000.00
Expand
